Drive Axle for Forklifts

Forklift Drive Axle - The piece of machinery which is elastically fastened to the frame of the vehicle utilizing a lift mast is referred to as the lift truck drive axle. The lift mast connects to the drive axle and could be inclined, by at the very least one tilting cylinder, around the axial centerline of the drive axle. Forward bearing components together with rear bearing parts of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle can be pivoted around a swiveling axis oriented horizontally and transversely in the vicinity of the back bearing parts. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is attached to the lift truck frame and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented nearly parallel to a plane extending from the axial centerline and to the swiveling axis.

Lift truck models like H45, H35 and H40 that are produced in Aschaffenburg, Germany by Linde AG, have the lift mast tilt capably affixed\connected on the vehicle framework. The drive axle is elastically connected to the lift truck frame utilizing many bearing tools. The drive axle consists of tubular axle body along with extension arms affixed to it and extend backwards. This type of drive axle is elastically connected to the vehicle frame using rear bearing parts on the extension arms along with frontward bearing devices situated on the axle body. There are two rear and two front bearing tools. Each one is separated in the transverse direction of the forklift from the other bearing machine in its respective pair.

The braking and drive torques of the drive axle on tis particular unit of lift truck are sustained using the extension arms through the rear bearing components on the framework. The forces generated by the lift mast and the load being carried are transmitted into the floor or roadway by the vehicle framework through the front bearing parts of the drive axle. It is essential to ensure the parts of the drive axle are installed in a firm enough way so as to maintain strength of the forklift truck. The bearing elements can lessen small bumps or road surface irregularities throughout travel to a limited extent and offer a bit smoother operation.
