Throttle Body for Forklift
Forklift Throttle Body - The throttle body is a component of the intake control system in fuel injected engines in order to regulate the amount of air flow to the engine. This particular mechanism works by placing pressure on the driver accelerator pedal input. Usually, the throttle body is placed between the intake manifold and the air filter box. It is usually attached to or placed close to the mass airflow sensor. The biggest piece inside the throttle body is a butterfly valve referred to as the throttle plate. The throttle plate's main task is to control air flow.
On most cars, the accelerator pedal motion is transferred through the throttle cable, thus activating the throttle linkages works to move the throttle plate. In automobiles with electronic throttle control, likewise known as "drive-by-wire" an electric motor regulates the throttle linkages. The accelerator pedal is attached to a sensor and not to the throttle body. This particular sensor sends the pedal position to the ECU or also known as Engine Control Unit. The ECU is responsible for determining the throttle opening based upon accelerator pedal position along with inputs from other engine sensors. The throttle body has a throttle position sensor. The throttle cable connects to the black portion on the left hand side that is curved in design. The copper coil placed close to this is what returns the throttle body to its idle position when the pedal is released.
Throttle plates turn within the throttle body each and every time pressure is placed on the accelerator. The throttle passage is then opened so as to permit much more air to flow into the intake manifold. Usually, an airflow sensor measures this change and communicates with the ECU. In response, the Engine Control Unit then increases the amount of fluid being sent to the fuel injectors in order to produce the desired air-fuel ratio. Frequently a throttle position sensor or likewise called TPS is connected to the shaft of the throttle plate so as to provide the ECU with information on whether the throttle is in the idle position, the wide-open position or also called "WOT" position or anywhere in between these two extremes.
To be able to control the least amount of air flow while idling, some throttle bodies may include adjustments and valves. Even in units which are not "drive-by-wire" there will normally be a small electric motor driven valve, the Idle Air Control Valve or also called IACV which the ECU utilizes to control the amount of air that can bypass the main throttle opening.
It is common that a lot of vehicles contain one throttle body, even if, more than one could be utilized and connected together by linkages to be able to improve throttle response. High performance automobiles like the BMW M1, along with high performance motorcycles like the Suzuki Hayabusa have a separate throttle body for each and every cylinder. These models are referred to as ITBs or "individual throttle bodies."
A throttle body is like the carburetor in a non-injected engine. Carburetors combine the functionality of the throttle body and the fuel injectors into one. They function by blending the fuel and air together and by regulating the amount of air flow. Cars which have throttle body injection, that is referred to as CFI by Ford and TBI by GM, locate the fuel injectors inside the throttle body. This enables an older engine the opportunity to be transformed from carburetor to fuel injection without really altering the engine design.
